16A magna Micro Switch Familiam Appliance Dustproof

Sicut Probatio exemplar of Yueqing Tongda Wire Electric Factory microform series, 16A Magnae Micro SWITCH Familiae Appliance Dustproof features "altae sensus, ultra-longam vitam, et multi-scenario aptabilitas" pro core utilitates eius. Integrata societas XXXV annorum peritia fabricandi, facta est clavis moderaminis componentis in adjumenta domestica, electronica automativa, automationis industriae, et in aliis agris, propter minimam contactum hiatum et celerem actionem mechanismum.

Model:HK-14-16AP-608

Mitte Inquisitionem

depictio producti

WEIPEG® est ducens16A magna Micro Switch Familiam Appliance Dustproof artifices, praebitores et exportatores.

Microform SWITCH PB

Fasciae flammeae retardant, summus temperatus-repugnans machinativa plastica, quae bonam velit habet, aetati vel deforme non facile est, et vexillum salutiferum retardat requisita flammea. Intus, GENEROSUS stannum argenteorum contactus adhibentur, qui conductionem stabilem praebent, arcubus electricis resistunt et exesa resistunt; crebra commutatione oxidatio vel sparking non facile causat contactum. Ex currenti conventionalis aestimatio plures specificationes 5A, 10A, 16A, 21A adiuvat, apta intentioni normae AC 125V/250V, necessitatibus moderandis minutissimis et mediae potentiae cogitationibus occurrens. Vita mechanica diuturnam et stabilem diuturnitatem habet.

Microform Parameter SWITCH PB (specification)

Technical Characteres switch:
ITEM	Technical Parameter		Precium
1	Electrical Rating		5(2)A/10A/16(3)A/21(8)A 250VAC
2	Contactus Resistentia		≤30mΩ valorem initial
3	Nulla Resistentia		≥100MΩ (500VDC)
4	Dielectric Voltage	inter non-connexa terminales	1000V/0.5mA/60S
		Inter terminals et metallum artus	3000V/0.5mA/60S
5	Vita electrica		≥50000 circuitus
6	Mechanica Vita		≥1000000 circuitus
7	Temperature operating		-25~ 125℃
8	Operating Frequency		electrica :15 circuitus Mechanica: LX circuitus
9	Vibratio Probatur		Vibratio Frequentia: 10~55HZ; Amplitude : 1.5 mm. Tres directiones: 1H
10	Facultates vendidit: Plus quam LXXX% de parte baptizati solida operietur		Temperature vendendi : 235± 5℃ Tempus baptizat: 2~3S
11	Solder Caloris Resistentia		Intingere solidamentum: 260±5℃ 5±1S Manuale solidamentum: 300±5℃ 2~3S
12	Salus Approvals		UL、CSA、VDE、ENEC、TUV、CE、KC、CQC
13	Tempestas test		Ambiens Temperature :20±5℃ Relativum Umor: 65±5% RH Pressura aeris: LXXXVI ~ 106KPa

Microform switch Feature et Application

1.Sate, certa basic switch
2. Pulchra species, stricta contiguatio. Charactenistic: parva contactu dlearance, actio velox, magna sensibilitas et parva 3. peregrinatio operans.
4.Long vitam, princeps reliablity
5.A varietate contactus terminales
6.A varnety temperatus gradus
7.A variis vectibus
8.Adopt themosetting plastic vel themoplastic
9. Late usus in home apliane elecroninc apparatusautomatic apparatus communicationis equioncar electron, apparatus et 10. instrumentum motus electrici etc.

Microform SWITCH PB Details
